1. Product introduction

JCY-2(S) adopts solution absorption method to collect harmful gases in flue pollution source, adopts high technology such as computer, sensor, automatic control, etc., which greatly improves the measurement accuracy, and can detect the temperature and pressure in front of the flowmeter in real time. Automatically accumulate sampling volume and standard sampling volume. It can be widely used in environmental monitoring, labor protection, industrial hygiene, factories and mines and other departments to sample harmful gases in pipeline pollution sources.

2. Product parameters

3. product features

1. Mold forming process, beautiful appearance, light weight, small size.
2. Imported precision electronic sensors with filters are used to automatically control the sampling flow according to the set value and constant current sampling. To ensure measurement accuracy, no positional influence, the performance is significantly better than the rotameter.
3. The rotary vane pump made of imported brushless DC motor is used as the sampling power, automatic lubrication, all stainless steel pump body, high suction negative pressure, stable flow, and trouble-free running time is more than 20,000 hours.
4. Original muffler to achieve super bass operation.
5. Automatically detect the pressure and temperature in front of the flowmeter, automatically calculate and display the sampling volume and standard volume, and have automatic fault protection function.
6. Automatic zero point correction and software parameter calibration to ensure measurement accuracy. Users can calibrate various parameters of the instrument through the keyboard, but need to enter with a password to ensure the security of instrument data.
7. Real-time clock, sampling time, date, flow, pressure, etc. are directly displayed, and the data is stored in 10,000 groups.
8. Adopt imported wide temperature OLED display, suitable for working in ultra-low temperature and low illumination environment, Chinese menu display, pictures and texts, easy to operate.
9. With timing sampling, interval sampling, multiple sampling, cyclic sampling and other sampling methods for customers to choose.
10. The instrument is equipped with a heated sampling tube, digital display of temperature, and titanium metal filter element to ensure measurement accuracy.
11. The unique three-in-one design of drying, filtration, and anti-sucking-back drying cylinder can efficiently dry moisture, filter dust, and reduce the impact on the flow rate by reducing the impact on the flow rate, achieving long-term operation without cleaning.
12. The built-in imported lithium battery can sample in the absence of AC power, and the instrument can work for dozens of hours. The sampling data is automatically memorized and set, and the next time it is turned on, it will be used first to realize one-click sampling.
13. The color recognition function of the gas path is convenient for users to connect the pipeline quickly and accurately. The left and right design of the sampling bottle avoids misoperation and facilitates gas connection. Tripod pan-table design, easy to operate.
14. The instrument is equipped with a rechargeable battery, which is used to save data during AC power failure. It automatically resumes sampling when AC power is on, and automatically deducts the power-down time during the sampling process, and allows users to query the power-down time.
