1. Product introduction

In order to control particulate pollution, the environmental protection department has increased the continuous online monitoring of pollutants emitted from the chimneys of industrial enterprises, including the measurement of smoke emission speed, particle concentration, and total emission. Although the traditional filter membrane sampling and weighing method is recognized as a detection method with relatively high reliability of measurement results, this method is extremely inefficient and cannot reflect the dynamic emission of particulate pollution in real time. has a certain risk. Therefore, the on-line continuous monitoring technology of smoke and dust with a high degree of automation has become the main monitoring method of particulate pollution. Light scattering particle concentration measurement technology has the characteristics of high sensitivity, fast response and small size, and has good development potential and application value in the field of particle pollution monitoring. It is suitable for industrial enterprises in cement, hydropower, steel, metallurgy, oil refining, aluminum, petrochemical, paper, glass and other industries.

2. Technical parameters

Measuring range: ( 0-50 ) mg/m³ ( maximum can be customized 0-100mg/m3 )

Flue gas velocity: 0-30m/s

Resolution: 0.001mg/ m³

Indication error: no more than ± 10%

Repeatability: ≤ 5%

Compliance with regulations & standards: JJG 846-2015 Verification Regulations for Dust Concentration Measuring Instruments

HJ/T76-2007 Technical Specification for Continuous Monitoring of Flue Gas Emission from Fixed Pollution Sources

3. Product Features

1. High sensitivity ( 0.001mg/m³ ) and high reliability, accurate monitoring of particle concentration in wet flue gas

2. All key units of the system have automatic control and performance testing functions, as well as automatic failure alarm functions (gasification chamber, light scattering unit and sampling unit)

3. Powerful user interface, built-in data log and data logging

4. Built-in self-diagnosis system

5. Modular design, easy to install

6. Convenient maintenance: The jet sampling and dilution sample gas pipelines are respectively equipped with pulse backflushing, and two modes of automatic cleaning and manual manual cleaning are designed in the control system, which is convenient for routine automatic maintenance of pipelines.
